KubeKey部署K8s集群教程(v1.28.8)

2024-11-05 18

KubeKey是一款用于简化Kubernetes集群部署的开源工具。它可以将K8s的安装过程简化为一条命令,支持多种平台和环境,旨在帮助用户快速搭建Kubernetes集群。本文将为大家演示如何在 openEuler 22.03 LTS SP3上,使用KubeKey部署一套纯粹的K8s集群。

主机名 IP CPU 内存 系统盘 数据盘 用途
ksp-master-1 192.168.9.131 8 16 40 100 k8s-master
ksp-master-2 192.168.9.132 8 16 40 100 k8s-master
ksp-master-3 192.168.9.133 8 16 40 100 k8s-master
合计 3 24 48 120 300
  • 操作系统:openEuler 22.03 LTS SP3 x64
  • K8s:v1.28.8
  • Containerd:1.7.13
  • KubeKey: v3.1.1

一、操作系统基础配置

本文仅选取 Master-1 节点进行演示,假设其他节点已经按照相同的配置和设置进行准备。注意除非特别说明,以下操作需要在所有服务器上执行。

1、配置主机名

hostnamectl hostname ksp-master-1

2、配置 DNS

echo "nameserver 114.114.114.114" > /etc/resolv.conf

3、配置服务器时区

配置服务器时区为 Asia/Shanghai。

timedatectl set-timezone Asia/Shanghai

4、配置时间同步

安装 chrony 作为时间同步软件:

yum install chrony

编辑配置文件 /etc/chrony.conf,修改 ntp 服务器配置:

vi /etc/chrony.conf# 删除所有的 pool 配置pool pool.ntp.org iburst# 增加国内的 ntp 服务器,或是指定其他常用的时间服务器pool cn.pool.ntp.org iburst# 上面的手工操作,也可以使用 sed 自动替换sed -i 's/^pool pool.*/pool cn.pool.ntp.org iburst/g' /etc/chrony.conf

重启并设置 chrony 服务开机自启动:

systemctl enable chronyd --now

验证 chrony 同步状态:

# 执行查看命令chronyc sourcestats -v# 正常的输出结果如下[root@ksp-master-1 ~]# chronyc sourcestats -v                             .- Number of sample points in measurement set.                            /    .- Number of residual runs with same sign.                           |    /    .- Length of measurement set (time).                           |   |    /      .- Est. clock freq error (ppm).                           |   |   |      /           .- Est. error in freq.                           |   |   |     |           /         .- Est. offset.                           |   |   |     |          |          |   On the -.                           |   |   |     |          |          |   samples. \                           |   |   |     |          |          |             |Name/IP Address            NP  NR  Span  Frequency  Freq Skew  Offset  Std Dev==============================================================================111.230.189.174            18  11   977     -0.693      6.795  -1201us  2207uselectrode.felixc.at        18  10   917     +2.884      8.258    -31ms  2532ustick.ntp.infomaniak.ch     14   7   720     +2.538     23.906  +6176us  4711ustime.cloudflare.com        18   7   913     +0.633      9.026  -2543us  3142us

5、关闭系统防火墙

systemctl stop firewalld && systemctl disable firewalld

6、禁用 SELinux

openEuler 22.03 SP3 最小化安装的系统默认启用了 SELinux,为了减少麻烦,我们所有的节点都禁用 SELinux。

# 使用 sed 修改配置文件,实现彻底的禁用sed -i 's/^SELINUX=enforcing/SELINUX=disabled/' /etc/selinux/config# 使用命令,实现临时禁用,这一步其实不做也行,KubeKey 会自动配置setenforce 0

7、安装系统依赖

在所有节点,执行下面的命令为 Kubernetes 安装系统基本依赖包。

# 安装 Kubernetes 系统依赖包yum install curl socat conntrack ebtables ipset ipvsadm# 安装 tar 包,不装的话后面会报错。openEuler 也是个奇葩,迭代这么多版本了,默认居然还不安装 taryum install tar

二、操作系统磁盘配置

服务器新增一块数据盘 /dev/sdb,用于 Containerd 和 K8s Pod 的持久化存储。为了满足部分用户希望在生产上线后,磁盘容量不足时可以实现动态扩容。本文采用了 LVM 的方式配置磁盘(实际上,本人维护的生产环境,几乎不用 LVM)。

1、使用 LVM 配置磁盘

创建 PV

 pvcreate /dev/sdb

创建 VG

vgcreate data /dev/sdb

创建 LV

# 使用所有空间,VG 名字为 data,LV 名字为 lvdatalvcreate -l 100%VG data -n lvdata

2、格式化磁盘

mkfs.xfs /dev/mapper/data-lvdata

3、磁盘挂载

手工挂载

mkdir /datamount /dev/mapper/data-lvdata /data/

开机自动挂载

tail -1 /etc/mtab >> /etc/fstab

4、创建数据目录

创建OpenEBS 本地数据根目录

mkdir -p /data/openebs/local

创建Containerd 数据目录

mkdir -p /data/containerd

创建 Containerd 数据目录软连接

ln -s /data/containerd /var/lib/containerd

说明: KubeKey 到 v3.1.1 版为止,一直不支持在部署的时候更改 Containerd 的数据目录,只能用这种目录软链接到变通方式来增加存储空间(也可以提前手工安装 Containerd)。

三、安装部署K8s

1、下载 KubeKey

下载最新版的 KubeKey

mkdir ~/kubekeycd ~/kubekey/# 选择中文区下载(访问 GitHub 受限时使用)export KKZONE=cncurl -sfL https://get-kk.kubesphere.io | sh -

正确的执行结果如下

[root@ksp-master-1 ~]# mkdir ~/kubekey[root@ksp-master-1 ~]# cd ~/kubekey/[root@ksp-master-1 kubekey]# export KKZONE=cn[root@ksp-master-1 kubekey]# curl -sfL https://get-kk.kubesphere.io | sh -Downloading kubekey v3.1.1 from https://kubernetes.pek3b.qingstor.com/kubekey/releases/download/v3.1.1/kubekey-v3.1.1-linux-amd64.tar.gz ...Kubekey v3.1.1 Download Complete![root@ksp-master-1 kubekey]# ll -htotal 114M-rwxr-xr-x. 1 root root 79M Apr 16 12:30 kk-rw-r--r--. 1 root root 36M Apr 25 09:37 kubekey-v3.1.1-linux-amd64.tar.gz

查看 KubeKey 支持的 Kubernetes 版本列表 ./kk version –show-supported-k8s

[root@ksp-master-1 kubekey]# ./kk version --show-supported-k8sv1.19.0......(受限于篇幅,中间的不展示,请读者根据需求查看)v1.28.0v1.28.1v1.28.2v1.28.3v1.28.4v1.28.5v1.28.6v1.28.7v1.28.8v1.29.0v1.29.1v1.29.2v1.29.3

2、创建 K8s 集群部署配置文件

(1)创建集群配置文件

本文选择了 K8s v1.28.8。因此,指定配置文件名称为 k8s-v1288.yaml,如果不指定,默认的文件名为 config-sample.yaml。

./kk create config -f k8s-v1288.yaml --with-kubernetes v1.28.8

(2)修改配置文件

示例采用 3 个节点同时作为 control-plane、etcd 和 worker 节点。

  • hosts:指定节点的 IP、ssh 用户、ssh 密码、ssh 端口
  • roleGroups:指定 3 个 etcd、control-plane 节点,复用相同的机器作为 3 个 worker 节点
  • internalLoadbalancer: 启用内置的 HAProxy 负载均衡器
  • domain:自定义域名 lb.opsxlab.cn,没特殊需求可使用默认值lb.kubesphere.local
  • clusterName:自定义 opsxlab.cn,没特殊需求可使用默认值cluster.local
  • autoRenewCerts:该参数可以实现证书到期自动续期,默认为 true
  • containerManager:使用 containerd

修改后的完整示例如下:

apiVersion: kubekey.kubesphere.io/v1alpha2kind: Clustermetadata:  name: samplespec:  hosts:  - {name: ksp-master-1, address: 192.168.9.131, internalAddress: 192.168.9.131, user: root, password: "OpsXlab@2024"}  - {name: ksp-master-2, address: 192.168.9.132, internalAddress: 192.168.9.132, user: root, password: "OpsXlab@2024"}  - {name: ksp-master-3, address: 192.168.9.133, internalAddress: 192.168.9.133, user: root, password: "OpsXlab@2024"}  roleGroups:    etcd:    - ksp-master-1    - ksp-master-2    - ksp-master-3    control-plane:    - ksp-master-1    - ksp-master-2    - ksp-master-3    worker:    - ksp-master-1    - ksp-master-2    - ksp-master-3  controlPlaneEndpoint:    ## Internal loadbalancer for apiservers    internalLoadbalancer: haproxy    domain: lb.opsxlab.cn    address: ""    port: 6443  kubernetes:    version: v1.28.8    clusterName: opsxlab.cn    autoRenewCerts: true    containerManager: containerd  etcd:    type: kubekey  network:    plugin: calico    kubePodsCIDR: 10.233.64.0/18    kubeServiceCIDR: 10.233.0.0/18    ## multus support. https://github.com/k8snetworkplumbingwg/multus-cni    multusCNI:      enabled: false  registry:    privateRegistry: ""    namespaceOverride: ""    registryMirrors: []    insecureRegistries: []  addons: []

3、部署K8s

接下来我们执行下面的命令,使用上面生成的配置文件部署 K8s。

export KKZONE=cn./kk create cluster -f k8s-v1288.yaml

上面的命令执行后,首先 KubeKey 会检查部署 K8s 的依赖及其他详细要求。通过检查后,系统将提示您确认安装。输入 yes 并按 ENTER 继续部署。

[root@ksp-master-1 kubekey]# ./kk create cluster -f k8s-v1288.yaml _   __      _          _   __| | / /     | |        | | / /| |/ / _   _| |__   ___| |/ /  ___ _   _|    \| | | | '_ \ / _ \    \ / _ \ | | || |\  \ |_| | |_) |  __/ |\  \  __/ |_| |\_| \_/\__,_|_.__/ \___\_| \_/\___|\__, |                                    __/ |                                   |___/10:45:28 CST [GreetingsModule] Greetings10:45:28 CST message: [ksp-master-3]Greetings, KubeKey!10:45:28 CST message: [ksp-master-1]Greetings, KubeKey!10:45:28 CST message: [ksp-master-2]Greetings, KubeKey!10:45:28 CST success: [ksp-master-3]10:45:28 CST success: [ksp-master-1]10:45:28 CST success: [ksp-master-2]10:45:28 CST [NodePreCheckModule] A pre-check on nodes10:45:31 CST success: [ksp-master-3]10:45:31 CST success: [ksp-master-1]10:45:31 CST success: [ksp-master-2]10:45:31 CST [ConfirmModule] Display confirmation form+--------------+------+------+---------+----------+-------+-------+---------+-----------+--------+--------+------------+------------+-------------+------------------+--------------+| name         | sudo | curl | openssl | ebtables | socat | ipset | ipvsadm | conntrack | chrony | docker | containerd | nfs client | ceph client | glusterfs client | time         |+--------------+------+------+---------+----------+-------+-------+---------+-----------+--------+--------+------------+------------+-------------+------------------+--------------+| ksp-master-1 | y    | y    | y       | y        | y     | y     | y       | y         | y      |        |            |            |             |                  | CST 10:45:31 || ksp-master-2 | y    | y    | y       | y        | y     | y     | y       | y         | y      |        |            |            |             |                  | CST 10:45:31 || ksp-master-3 | y    | y    | y       | y        | y     | y     | y       | y         | y      |        |            |            |             |                  | CST 10:45:31 |+--------------+------+------+---------+----------+-------+-------+---------+-----------+--------+--------+------------+------------+-------------+------------------+--------------+This is a simple check of your environment.Before installation, ensure that your machines meet all requirements specified athttps://github.com/kubesphere/kubekey#requirements-and-recommendationsContinue this installation? [yes/no]:

注意:

  • nfs client、ceph client、glusterfs client 3 个与存储有关的 client 显示没有安装,这个我们后期会在对接存储的实战中单独安装。
  • docker、containerd 会根据配置文件选择的 containerManager类型自动安装。

解释:

10:59:25 CST [ConfigureKubernetesModule] Configure kubernetes10:59:25 CST success: [ksp-master-1]10:59:25 CST skipped: [ksp-master-2]10:59:25 CST skipped: [ksp-master-3]10:59:25 CST [ChownModule] Chown user $HOME/.kube dir10:59:26 CST success: [ksp-master-3]10:59:26 CST success: [ksp-master-2]10:59:26 CST success: [ksp-master-1]10:59:26 CST [AutoRenewCertsModule] Generate k8s certs renew script10:59:27 CST success: [ksp-master-2]10:59:27 CST success: [ksp-master-3]10:59:27 CST success: [ksp-master-1]10:59:27 CST [AutoRenewCertsModule] Generate k8s certs renew service10:59:28 CST success: [ksp-master-3]10:59:28 CST success: [ksp-master-2]10:59:28 CST success: [ksp-master-1]10:59:28 CST [AutoRenewCertsModule] Generate k8s certs renew timer10:59:29 CST success: [ksp-master-2]10:59:29 CST success: [ksp-master-3]10:59:29 CST success: [ksp-master-1]10:59:29 CST [AutoRenewCertsModule] Enable k8s certs renew service10:59:29 CST success: [ksp-master-3]10:59:29 CST success: [ksp-master-2]10:59:29 CST success: [ksp-master-1]10:59:29 CST [SaveKubeConfigModule] Save kube config as a configmap10:59:29 CST success: [LocalHost]10:59:29 CST [AddonsModule] Install addons10:59:29 CST success: [LocalHost]10:59:29 CST Pipeline[CreateClusterPipeline] execute successfullyInstallation is complete.Please check the result using the command:        kubectl get pod -A

四、验证K8s集群

1、kubectl 命令行验证集群状态

本小节只是简单的看了一下基本状态,并不全面,更多的细节大家自己体验探索吧。

(1)查看集群节点信息

在 master-1 节点运行 kubectl 命令获取 K8s 集群上的可用节点列表。

kubectl get nodes -o wide

在输出结果中可以看到,当前的 K8s 集群有三个可用节点、节点的内部 IP、节点角色、节点的 K8s 版本号、容器运行时及版本号、操作系统类型及内核版本等信息。

解释:

[root@ksp-master-1 kubekey]# kubectl get nodes -o wideNAME           STATUS   ROLES                  AGE     VERSION   INTERNAL-IP     EXTERNAL-IP   OS-IMAGE                    KERNEL-VERSION                       CONTAINER-RUNTIMEksp-master-1   Ready    control-plane,worker   9m43s   v1.28.8   192.168.9.131   <none>        openEuler 22.03 (LTS-SP3)   5.10.0-182.0.0.95.oe2203sp3.x86_64   containerd://1.7.13ksp-master-2   Ready    control-plane,worker   8m8s    v1.28.8   192.168.9.132   <none>        openEuler 22.03 (LTS-SP3)   5.10.0-182.0.0.95.oe2203sp3.x86_64   containerd://1.7.13ksp-master-3   Ready    control-plane,worker   8m9s    v1.28.8   192.168.9.133   <none>        openEuler 22.03 (LTS-SP3)   5.10.0-182.0.0.95.oe2203sp3.x86_64   containerd://1.7.13

(2)查看 Pod 列表

输入以下命令获取在 K8s 集群上运行的 Pod 列表。

kubectl get pods -o wide -A

在输出结果中可以看到, 所有 pod 都在运行。

解释:

[root@ksp-master-1 kubekey]# kubectl get pod -A -o wideNAMESPACE     NAME                                       READY   STATUS    RESTARTS   AGE     IP              NODE        kube-system   calico-kube-controllers-64f6cb8db5-fsgnq   1/1     Running   0          4m59s   10.233.84.2     ksp-master-1           kube-system   calico-node-5hkm4                          1/1     Running   0          4m59s   192.168.9.133   ksp-master-3          kube-system   calico-node-wqz9s                          1/1     Running   0          4m59s   192.168.9.132   ksp-master-2kube-system   calico-node-zzr5n                          1/1     Running   0          4m59s   192.168.9.131   ksp-master-1kube-system   coredns-76dd97cd74-66k8z                   1/1     Running   0          6m22s   10.233.84.1     ksp-master-1kube-system   coredns-76dd97cd74-94kvl                   1/1     Running   0          6m22s   10.233.84.3     ksp-master-1kube-system   kube-apiserver-ksp-master-1                1/1     Running   0          6m39s   192.168.9.131   ksp-master-1kube-system   kube-apiserver-ksp-master-2                1/1     Running   0          4m52s   192.168.9.132   ksp-master-2kube-system   kube-apiserver-ksp-master-3                1/1     Running   0          5m9s    192.168.9.133   ksp-master-3kube-system   kube-controller-manager-ksp-master-1       1/1     Running   0          6m39s   192.168.9.131   ksp-master-1kube-system   kube-controller-manager-ksp-master-2       1/1     Running   0          4m58s   192.168.9.132   ksp-master-2kube-system   kube-controller-manager-ksp-master-3       1/1     Running   0          5m5s    192.168.9.133   ksp-master-3kube-system   kube-proxy-2xpq4                           1/1     Running   0          5m3s    192.168.9.131   ksp-master-1kube-system   kube-proxy-9frmd                           1/1     Running   0          5m3s    192.168.9.133   ksp-master-3kube-system   kube-proxy-bhg2k                           1/1     Running   0          5m3s    192.168.9.132   ksp-master-2kube-system   kube-scheduler-ksp-master-1                1/1     Running   0          6m39s   192.168.9.131   ksp-master-1kube-system   kube-scheduler-ksp-master-2                1/1     Running   0          4m59s   192.168.9.132   ksp-master-2kube-system   kube-scheduler-ksp-master-3                1/1     Running   0          5m5s    192.168.9.133   ksp-master-3kube-system   nodelocaldns-gl6dc                         1/1     Running   0          6m22s   192.168.9.131   ksp-master-1kube-system   nodelocaldns-q45jf                         1/1     Running   0          5m9s    192.168.9.133   ksp-master-3kube-system   nodelocaldns-rskk5                         1/1     Running   0          5m8s    192.168.9.132   ksp-master-2

(3)查看 Image 列表

输入以下命令获取在 K8s 集群节点上已经下载的 Image 列表。

[root@ksp-master-1 kubekey]# crictl images lsIMAGE                                                                   TAG                 IMAGE ID            SIZEregistry.cn-beijing.aliyuncs.com/kubesphereio/cni                       v3.27.3             6527a35581401       88.4MBregistry.cn-beijing.aliyuncs.com/kubesphereio/coredns                   1.9.3               5185b96f0becf       14.8MBregistry.cn-beijing.aliyuncs.com/kubesphereio/k8s-dns-node-cache        1.22.20             ff71cd4ea5ae5       30.5MBregistry.cn-beijing.aliyuncs.com/kubesphereio/kube-apiserver            v1.28.8             e70a71eaa5605       34.7MBregistry.cn-beijing.aliyuncs.com/kubesphereio/kube-controller-manager   v1.28.8             e5ae3e4dc6566       33.5MBregistry.cn-beijing.aliyuncs.com/kubesphereio/kube-controllers          v3.27.3             3e4fd05c0c1c0       33.4MBregistry.cn-beijing.aliyuncs.com/kubesphereio/kube-proxy                v1.28.8             5ce97277076c6       28.1MBregistry.cn-beijing.aliyuncs.com/kubesphereio/kube-scheduler            v1.28.8             ad3260645145d       18.7MBregistry.cn-beijing.aliyuncs.com/kubesphereio/node                      v3.27.3             5c6ffd2b2a1d0       116MBregistry.cn-beijing.aliyuncs.com/kubesphereio/pause                     3.9                 e6f1816883972       321kB

五、部署测试资源

1、创建Nginx Deployment

运行以下命令创建一个部署 Nginx Web 服务器的 Deployment。此示例中,我们将创建具有两个副本基于 nginx:alpine 镜像的 Pod。

kubectl create deployment nginx --image=nginx:alpine --replicas=2

2、创建Nginx Service

创建一个新的 K8s 服务,服务名称 nginx,服务类型 Nodeport,对外的服务端口 80。

kubectl create service nodeport nginx --tcp=80:80

3、验证Nginx Deployment和Pod

运行以下命令查看创建的 Deployment 和 Pod 资源。

kubectl get deployment -o widekubectl get pods -o wide

查看结果如下:

[root@ksp-master-1 kubekey]# kubectl get deployment -o wideNAME    READY   UP-TO-DATE   AVAILABLE   AGE   CONTAINERS   IMAGES         SELECTORnginx   2/2     2            2           20s   nginx        nginx:alpine   app=nginx[root@ksp-master-1 kubekey]# kubectl get pods -o wideNAME                     READY   STATUS    RESTARTS   AGE   IP               NODE          NOMINATED NODE   READINESS GATESnginx-6c557cc74d-tbw9c   1/1     Running   0          23s   10.233.102.187   ksp-master-2   <none>           <none>nginx-6c557cc74d-xzzss   1/1     Running   0          23s   10.233.103.148   ksp-master-1   <none>           <none>

4、验证Nginx Service

运行以下命令查看可用的服务列表,在列表中我们可以看到 nginx 服务类型 为 Nodeport,并在 Kubernetes 主机上开放了 30619 端口。

kubectl get svc -o wide

查看结果如下:

[root@ksp-master-1 kubekey]# kubectl get svc -o wideNAME         TYPE        CLUSTER-IP     EXTERNAL-IP   PORT(S)        AGE     SELECTORkubernetes   ClusterIP   10.233.0.1     <none>        443/TCP        4d22h   <none>nginx        NodePort    10.233.14.48   <none>        80:30619/TCP   5s      app=nginx

5、验证服务

运行以下命令访问部署的 Nginx 服务,验证服务是否成功部署。

验证直接访问 Pod

curl 10.233.102.187# 访问结果如下[root@ks-master-1 ~]# curl 10.233.102.187<!DOCTYPE html><html><head><title>Welcome to nginx!</title><style>html { color-scheme: light dark; }body { width: 35em; margin: 0 auto;font-family: Tahoma, Verdana, Arial, sans-serif; }</style></head><body><h1>Welcome to nginx!</h1><p>If you see this page, the nginx web server is successfully installed andworking. Further configuration is required.</p><p>For online documentation and support please refer to<a href="http://nginx.org/" rel="external nofollow" >nginx.org</a>.<br/>Commercial support is available at<a href="http://nginx.com/" rel="external nofollow" >nginx.com</a>.</p><p><em>Thank you for using nginx.</em></p></body></html>

验证访问 Service

curl 10.233.14.48# 访问结果同上,略

验证访问 Nodeport

curl 192.168.9.131:30619# 访问结果同上,略
